Reviews
Part of Ceramics projects sized for one kiln shelf, chosen to build skill fast
Clay and Glaze Materials for Small Ceramics Projects
Clay and glaze materials for small ceramics projects: how silica, fluxes and alumina work, which raw powders are hazardous, and why glaze fit decides.
Material choice in ceramics for small ceramics projects is really two choices, made together: a clay body and a glaze that fits it. Get the pair right and most other problems get easier. Get it wrong and no amount of careful making saves the piece.
What to take away
- Pick one clay body and one firing temperature, then choose glazes to suit them.
- A glaze is three thingsa glass former, a flux to melt it, and alumina to stop it running.
- Several common glaze materials are toxic in the raw powder. Read what is in the tub.
- Glaze fit, not glaze color, is what decides whether a small pot survives use.
Start with the clay body
Choose the body first because it fixes the firing temperature, and the firing temperature fixes which glazes are even candidates. For small functional work, a mid-fire or high-fire stoneware is the straightforward answer: it vitrifies, so it does not stay porous, and it is forgiving about glaze thickness. Mid-fire means roughly cone 5 to cone 6, and high-fire starts around cone 9.
Then stop changing it. Every body has its own shrinkage, its own color and its own glaze fit, so switching bodies invalidates everything you learned about your glazes.
What a glaze is made of
Glaze is not a paint. A college primer on basic glaze technology defines it as a liquid suspension of finely ground minerals that melts into a glassy coat when fired, and breaks every glaze into three roles. Silica is the glass former, with a melting point around 3119 degrees Fahrenheit on its own, far above any pottery kiln.
Three roles in a glaze
Silica
- Role
- Glass former
- Melting point
- 3119 F alone
- Common
- Silica, feldspar
- Too much
- Dry, underfired
Flux
- Role
- Melts it
- Melting point
- Lowers it
- Common
- Sodium, calcium, lead
- Too much
- Runs off wall
Alumina
- Role
- Stabilizer
- Melting point
- Stiffens melt
- Common
- Kaolin, hydrate
- Too much
- Dry matte surface
Fluxes bring that down, and the common ones are sodium, potassium, calcium, barium, magnesium, zinc, lithium and lead. Alumina is the stabilizer that stiffens the melt so the glaze stays on a vertical wall instead of running to the shelf.
That three-part structure explains most glaze faults. Too much flux and it runs. Too little and it stays dry and underfired. Change the body underneath it and the fit changes.
Read what is in the tub
Raw glaze materials are chemicals, and some are genuinely dangerous in powder form. A university dictionary of ceramic raw materials is blunt about several. Antimony oxide is slightly soluble and very toxic. Barium carbonate has limited use partly because of its toxicity. Materials like bone ash and borax cause crawling, pinholing or blistering when overused.
Raw materials to watch
- Antimony oxideslightly soluble, very toxic
- Barium carbonatelimited use, toxicity
- Bone ashcrawling when overused
- Boraxpinholing or blistering if overdone
- Silica and feldsparrespirable dust
- Prepared glazesavoid raw powders
| Role | Common materials | What to watch |
|---|---|---|
| Glass former | Silica, feldspar | Respirable dust in the raw powder |
| Flux | Whiting, feldspar, borax, barium, lithium | Toxicity of some; running if overdone |
| Stabilizer | Kaolin, alumina hydrate | Too much gives a dry, matte underfired surface |
| Color | Iron, cobalt, copper, mason stains | Metal content; food-contact suitability |
For small functional work, prepared glazes from a supplier remove most of this risk, because you are not handling raw powders at all. That is a reasonable trade for a home studio.
Know the rules that apply
Two pieces of paperwork cover most of the safety side in the United States. Under OSHA's Hazard Communication Standard, every supplier ships a safety data sheet (SDS) with raw materials, so the hazards and handling instructions arrive in writing rather than as rumor.
For fired ware that will touch food, the FDA enforces limits on lead release from glazed ceramicware, ASTM C738 is the standard test method for lead and cadmium extracted from glazed ceramic surfaces, and California's Proposition 65 is why some commercial glazes carry a warning label. Those rules apply to the fired, finished piece, not to the jar on the shelf.
Fit matters more than color
A glaze that does not fit the body crazes or shivers. Both are structural, not cosmetic. Crazed glaze on a mug traps bacteria in the cracks; shivered glaze sheds slivers.
Test any new glaze on the body you actually use, at the thickness you actually apply, and fire it in your own kiln before you trust it. Slot those tests into the small project rotation, keep them to one variable at a time, and label every test tile with what it was.
Common questions
Is a commercial glaze safe for a mug?
Only when fired as the maker directs, on a suitable body, at the right thickness. The label describes the glaze, not your fired result.
Why does my glaze look different on two clay bodies?
Because the body contributes. Iron in a dark body will move color and can bleed through a thin coat. That is why holding the body constant matters.
Should I mix glazes from raw materials?
Not at first. Mixing means handling dry powders, which brings ventilation, respirators and gloves into a home studio that may not be set up for them.
How do I know a body has vitrified?
Fire a test tile, weigh it, soak it in water for a day and weigh it again. A body that gains very little water has vitrified; one that gains a lot has not.
